GeChic M505T 15.6 inch FHD 1080p Portable Touchscreen Monitor USB Type-C Input, HDMI Input/Output, DC-in Port, Daisy Chain Display for Conference, Factory, Industry, Gaming, Foldable Screen
Product details
| Management number | 219725714 | Release Date | 2026/05/03 | List Price | US$140.00 | Model Number | 219725714 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
GeChic M505T Portable Touchscreen Monitor Specifications: Panel: 15.6” (16:9) wide Active Area: 344mm*194mm (WxH) Pixel Pitch: 0.179mm (H) *0.179mm (V) Resolution: 1920 x 1080 Color Depth: 16.7M Colors Brightness: 250 (cd/m²) (Typical) Contrast: 700:1(Typical) Viewing Angle: 170°(H)/170°(V)(CR>10) Response Time (GTG): 15(ms)(Typical) Touch Input: Finger or passive stylus( Diameter of Touch Point ≧ 6.0mm) Operation System: Windows 10 HDMI Video Display: 1920x1080P(50Hz/59.94Hz/60Hz); 1280x720P(50Hz/59.94Hz/60Hz); 720x480P(59.94Hz/60Hz); 640x480P(59.94Hz/60Hz) Supported resolutions: 1920*1080(60Hz);1600*900(60Hz); 1440*900(60Hz); 1366*768(60Hz) 1280*1024(60Hz);1280*960(60Hz); 1280*800(60Hz);1280*768(60Hz); 1280*720(60Hz); 1024*768(60Hz) Video Input: HDMI, USB Type-C(DP1.2)*1 Video Output: HDMI-A*1 (HDMI LOOP: Up to 14 monitors) The number of monitor loop depends on different HDMI cable,HDMI Video signal and other variable factors.The actual units of the monitor loop may more or less than 14 pcs. USB Output: No HDCP Support: Yes USB-C Power Delivery Support: No Audio Output: Earphone jack (3.5mm mini jack) Speaker: 1.5W(Max.) X2 Rating Power: 5V-2.0A Connectivity: HDMI-IN *1 HDMI-OUT *1 USB Type-C (DP1.2) *1 Cabinet Colors: Front: Black Back: Black Dimension(WxHXD): Display top cover: 364mm*250mm*7.2mm I/O Base: 364mm*135mm*10.7mm Weight: 1145g(monitor) Accessories in package: HDMI-A Video Cable(1.2m)*1 USB Type-C Video Cable(1.0m)*1 USB-A to USB-C Power and Touch Signal Cable(1.2m)*1 5V 2A Adapter
- PORTABLE TOUCH MONITOR: 15.6” FHD 1920x1080 with HDMI, USB Type-C inputs & HDMI output, DC-IN port
- SENSITIVE PROJECTIVE CAPACITIVE TOUCH SCREEN: Support ten-finger multi-touch and wet finger operation
- CUSTOM TOUCH SENSITIVITY: Adjust the sensitivity with different touch media to meet your needs
- DAISY CHAINING WITH MULTIPLE MONITORS: GeChic M505T can be looped up to 14 units through HDMI input and output
- SMART FOLDABLE DESIGN: Integrating the functions of input/output ports, OSD buttons in screen and I/O docking combined base with hinges. Supporting from 40° to 85° stepless viewing angles
| Brand | Gechic |
|---|---|
| Color | black |
| Voltage | 5 Volts |
| Brightness | 250 |
| Model Name | GeChic M505T |
| Resolution | FHD 1080p |
| Unit Count | 1.0 Count |
| Item Weight | 2.07 Kilograms |
| Screen Size | 15.6 Inches |
| Aspect Ratio | 16:9 |
| Display Type | LED |
| Manufacturer | GeChic |
| Model Number | GeChic M505T |
| Refresh Rate | 60 Hz |
| Adaptive Sync | FreeSync |
| BuiltIn Media | HDMI-A Video Cable(1.2m)*1 USB Type-C Video Cable(1.0m)*1 USB-A to USB-C Power and Touch Signal Cable(1.2m)*1 5V 2A Adapter*1 |
| Mounting Type | Wall Mount |
| Response Time | 15 Milliseconds |
| Screen Finish | Glossy |
| Viewing Angle | 90 Degrees |
| Warranty Type | Limited Warranty |
| Contrast Ratio | 700:1 |
| Total Usb Ports | 1 |
| Has Color Screen | Yes |
| Native Resolution | 1920x1080 |
| Compatible Devices | Laptops, Desktops, Gaming Consoles |
| Display Technology | LCD |
| Total USB 30 Ports | 1 |
| Additional Features | Touchscreen |
| Warranty Description | 1 year limited |
| Hardware Connectivity | 3.5mm Audio, HDMI, USB Type C |
| Connectivity Technology | HDMI-IN *1 HDMI-OUT *1 USB Type-C (DP1.2) *1 |
| Item Dimensions D x W x H | 20"D x 14"W x 3"H |
| Specific Uses For Product | Gaming |
| Display Resolution Maximum | 1920 x 1080 |
| Total Number of HDMI Ports | 1 |
| Number of Component Outputs | 1 |
| Picture Quality Enhancement Technology | freesync |
